Speedo Marine (Pte) Ltd.

Flotech 45:1
Product Code & Goods Description
1857
Chargeable weight: 101.000 Kg
Dimensions : 81.000 x 68.000 x 128.000 cm

The Flotech Airless 45:1 Spray Pump is ideal for applications to do with roofing, construction, metal structures, high viscosity coating, and protective coating, and typically handles fluids such as epoxy primers, alkyds, tar-epoxies, paints for corrosion control etc.

The Flotech Spray Pump 45:1 Complete Package includes:

  • S-Plus Gun C/W G269517 Tip & Tip Filter 60#
  • Gun Swivel
  • 1/4" x 50’ Paint Hose (3300 PSI)
Quantity
Technical Specifications

FLUID PRESSURE RATIO

45:1

DELIVERY

3.98 (15) gpm (litre/min)

MAX. PUMP SPEED

60 cycle/min

AIR MOTOR EFFECTIVE DIAMETER

10 (254) inch (mm)

STROKE

120mm

MAX. INLET PRESSURE

100 (7) psi (BAR))

MAX. OUTLET PRESSURE

4500 (310) psi (BAR)

AIR INLET SIZE

3/4" (PT)

FLUID INLET SIZE

1" (PT)



Optional: Wetted parts are available in stainless steel.

Alternative packing stacks are available, depending on the type of fluid handled.
