Speedo Marine (Pte) Ltd.

DD50 (2")
Product Code & Goods Description

Flotech air-operated diaphragm pumps are ideal for unloading above or below ground tanks of any size. They are available in a wide range of materials of construction in sizes including: 1/2" (12.7mm), 3/4" (19.1mm), 1” (25.4mm), 1-1/2” (38.1mm), 2” (50.8mm), and 3” (76.2mm).

Fewer moving parts means increased durability and less repair time. The pumps also feature a three-way pilot valve for true non-sticking operation, and are externally serviceable for quick, inexpensive repairs.

Quantity
Technical Specifications

DD50AL-AL/HY/HY/HY
Max. Working Pressure: 123 psi
Max. Delivery rate: 587 lpm
Fluid inlet & outlet size: 2" bspt(f)
Air inlet size: 1/2"bspt(f)
Wetted parts: Aluminium
Diaphragm: Hytrel
Balls: Hytrel
Seats: Hytrel

DD50PP-PP/TF/TF/PP
Max. Working Pressure: 123 psi
Max. Delivery rate: 587 lpm
Fluid inlet & outlet size: 2" flange
Air inlet size: 1/2" bspt(f)
Wetted parts: Polypropylene
Diaphragm: Teflon
Balls: Teflon
Seats: Polypropylene

DD50PP-SS/TF/TF/SS
Max. Working Pressure: 123 psi
Max. Delivery rate: 587 lpm
Fluid inlet & outlet size: 2" bspt(f)
Air inlet size: 1/2" bspt(f)
Wetted parts: Stainless Steel
Diaphragm: Teflon
Balls: Teflon
Seats: Stainless Steel
